Y1120

Modular oven dedicated to the manufacture of composite parts in vacuum bags.

Intérieur rogné-compressed

⚙️ Equipment :

FE3000 monitoring system with barcode scanner
Automated control system with "Cofrac" calibrated control probes:
IHM
Temperature regulation management
Programmable via the oven monitoring software
1 48-channel recorder
1 set of temperature and vacuum:

Interior right side :

24 female connectors for K-type thermocouples
16 internal vacuum ports
16 vacuum measurements

Exterior right side :

2 vacuum pumps
1 vacuum reserve
1 vacuum manifold with 16 solenoid valves, 16 particle filters

Left side : all the connections (K-type thermocouples and vacuum)
8 liquid traps
Air renewal and cooling extractor
Insulating panel under the floor with an access ramp
Air conditioner on top of the electrical cabinet

🔧 Features :

Prises vide + prises TCJ-compressed

Circuit vide-compressed

Vue manuel + pièges devis + photo pièges-compressed

Supervisory system: management, precision and reliability!

Developed by France Etuves!

Supervision FE3000 site-1

📈 Supervision :

Revenue management to control all system parameters
Management of all system parameters, both controlled and measured, including temperatures, pressures, mixing speeds, air renewal settings…
Recipe launch, automatic execution
Displaying parameters in "Overview", "Parameters", and "Graph" modes
Recording parameters in an SQL database over time
Analysis of parameter recordings, graphical visualization
Report and inspection report preparation
Extraction in CSV format for use with spreadsheets
