E765 - France Etuves

This modular oven is made up of 4 sections of 224m³ each one.

Volume: 4x224 m³
Maximum Temperature: 200°C
Inner Casing Size of a section: 6900 x 8150 x 3956 mm
Wattage per section: 87 000 Watts

Designed for the polymerization of composites hull of a boat at 180°C

Homogeneity better than ±1,5°C at 180°C

No plate

Ventilation is ensured by 2 centrifugal fans for each section, aspiration and blowing through ventilation openings equipped with adjustable flaps located on the ceiling and on the lateral sides

2 groups of heating elements of 33 kW each one per section

4 hydraulic actuators with manual pump to lift the section for moving

Broadcast of the set point temperature from the first section to the last

Possibility of heating with simple control or according to programs

Each section has visual, electronic and mechanical safeties
